H3C S5560X-EI Series User Manual

56
Item S5560X-30C-EI S5560X-54C-EI S5560X-30F-EI S5560X-54F-EI
Management
Ethernet port
1 1 1 1
SFP+ port 4 4 4 4
SFP port
8 (Each and its
corresponding
10/100/1000BASE-T
port form a combo
interface.)
N/A
24 (The rightmost
eight SFP ports and
their corresponding
10/100/1000BASE-T
autosensing
Ethernet ports form
combo interfaces.)
48
10/100/1000
BASE-T
autosensing
Ethernet port
24 48
8 (Each and its
corresponding SFP
port form a combo
interface.)
N/A
Expansion
slot
1, on the rear panel 1, on the rear panel 1, on the rear panel 1, on the rear panel
Power
module slot
2, on the rear panel 2, on the rear panel 2, on the rear panel 2, on the rear panel
Fan tray slot 2, on the rear panel 2, on the rear panel 2, on the rear panel 2, on the rear panel
Input voltage
• AC input for the PSR150-A1 or PSR150-A2 power module:
{ Rated voltage range: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
{ Max voltage range: 90 VAC to 264 VAC @ 47 Hz to 63 Hz
• DC input for the PSR150-D1 power module:
You can use a –48 VDC power source in the equipment room or an RPS (RPS800-A or
RPS1600-A).
{ Rated voltage range: –48 VDC to –60 VDC
{ Max voltage range: –36 VDC to –72 VDC\
Minimum
power
consumption
• Single AC input:
24 W
• Single DC input:
24 W
• Dual AC inputs:
29 W
• Dual DC inputs:
28 W
• Single AC
input: 27 W
• Single DC
input: 24 W
• Dual AC
inputs: 31 W
• Dual DC
inputs: 29 W
• Single AC input:
24 W
• Single DC input:
24 W
• Dual AC inputs:
29 W
• Dual DC inputs:
30 W
• Single AC
input: 30 W
• Single DC
input: 30 W
• Dual AC inputs:
37 W
• Dual DC
inputs: 36 W
Maximum
power
consumption
• Single AC input:
87 W
• Single DC input:
88 W
• Dual AC inputs:
91 W
• Dual DC inputs:
95 W
• Single AC
input: 88 W
• Single DC
input: 89 W
• Dual AC
inputs: 93 W
• Dual DC
inputs: 96 W
• Single AC input:
112 W
• Single DC input:
113 W
• Dual AC inputs:
116 W
• Dual DC inputs:
122 W
• Single AC
input: 130 W
• Single DC
input: 132 W
• Dual AC inputs:
134 W
• Dual DC
inputs: 140 W
Chassis
leakage
current
compliance
UL60950-1, EN60950-1, IEC60950-1, GB4943
Melting
current of
power
module fuse
• PSR150-A1/PSR150-A2 power module: 5 A, 250 V
• PSR150-D1 power module: 8 A, 250 V
