Mounting brackets
Table 4 Mounting brackets available for the switch
Switch model
Front mounting brackets
(Figure 4)
Rear mou
nting bracket and
shoulder screw (Figure 5)
S6520X-16ST-SI
S6520X-24ST-SI
S6520X-10XT-SI
S6520X-16XT-SI
S6520X-18C-SI
S6520X-26C-SI
S6520X-26MC-SI
Provided N/A
S6520X-26MC-UPWR-SI
S6520X-26XC-UPWR-SI
S6520X-54XC-UPWR-SI
Provided Provided
Figure 4 Front mounting bracket
(1) Screw hole for attaching the bracket to the switch (2) Screw hole for attaching the bracket to the rack
(3) M4 screw
Figure 5 Rear mounting bracket and shoulder screw
(1) Screw hole for attaching the bracket to the rack (2) Shoulder screw
