H3C S6520-SI Series User Manual

67
SFP port
An LSP4G4T6P interface module provides six SFP ports. You can install GE SFP transceiver
modules in Table 20 a
nd GE SFP cables in Table 21 in the SFP ports.
SFP+ port
The following switches provide fixed SFP+ ports on the front panel:
• S6520X-16ST-SI
• S6520X-24ST-SI
• S6520X-18C-SI
• S6520X-10XT-SI
• S6520X-16XT-SI
• S6520X-26C-SI
To connect peer SFP+ ports over a long distance, use SFP/SFP+ transceiver modules and fibers. To
connect peer SFP+ ports over a short distance, use SFP/SFP+ cables. You can install GE SFP
transceiver modules in Table 20, GE SFP
cables in Table 21,10-GE SFP+ transceiver modules
in Table 22, a
nd 10-GE SFP+ cables in Table 23 in the SFP+ ports.
Table 20 GE SFP transceiver modules available for the SFP and SFP+ ports
GE SFP
transceiver
module
Central
wavelength
(nm)
Connector
Cable/Fiber
type and
diameter (µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
SFP-GE-T N/A RJ-45
Twisted pair
cable
N/A 100 m (328.08 ft)
SFP-GE-T-D N/A RJ-45
Twisted pair
cable
N/A 100 m (328.08 ft)
SFP-GE-SX-MM
850-A
850 LC
Multi-mode,
50/125
500 550 m (1804.46 ft)
400 500 m (1640.42 ft)
Multi-mode,
62.5/125
200 275 m (902.23 ft)
160 220 m (721.78 ft)
SFP-GE-SX-MM
850-D
850 LC
Multi-mode,
50/125
500 550 m (1804.46 ft)
400 500 m (1640.42 ft)
Multi-mode,
62.5/125
200 275 m (902.23 ft)
160 220 m (721.78 ft)
SFP-GE-LX-SM1
310-A
1310 LC
Single-mode,
9/125
N/A 10 km (6.21 miles)
Multi-mode,
50/125
500 or 400 550 m (1804.46 ft)
Multi-mode,
62.5/125
500 550 m (1804.46 ft)
SFP-GE-LX-SM1
310-D
1310 LC
Single-mode,
9/125
N/A 10 km (6.21 miles)
SFP-GE-LH40-S
M1310
1310 LC
Single-mode,
9/125
N/A
40 km (24.86
miles)
