55
information about installing and removing a power module, see "Installing and removing a power
module."
The S6520X-54XC-UPWR-SI switch comes with the three fan tray slots empty. You must install three
fan trays of the same model for the switch. In Figure 69, three LSPM1F
ANSB fan trays are installed
in the fan tray slots. For information about installing and removing a fan tray, see "Installing and
removin
g a fan tray."
An S6520X-54XC-UPWR-SI switch comes with a filler panel in the expansion slot. You can select an
expansion card for the switch as required. In Figure 69, an LSWM2
SP2PM interface card is installed
in the expansion slot. For more information about installing and removing an expansion card, see
"Installing and removing an expansion card."
Technical specifications
Table 9 Technical specifications of non-PoE switches (1)
Item
S6520X-16ST-
SI
S6520X-24ST-
SI
S6520X-18C
-SI
S6520X-26C
-SI
S6520X-26
MC-SI
Dimensions (H
× W × D)
43.6 × 440 × 360 mm (1.72 × 17.32 × 14.17 in)
Weight 5 kg (11.02 lb) 5 kg (11.02 lb)
5 kg (11.02
lb)
5 kg (11.02
lb)
6 kg (13.23
lb)
Console port
1 × micro USB console port
1 × serial console port
Only the micro USB console port is available when you connect both ports.
USB port 1 1 1 1 1
Management
Ethernet port
1 1 1 1 1
SFP+ port
16 (The two
highest-number
ed SFP+ ports
form combo
interfaces with
their
corresponding
1/10GBASE-T
autosensing
Ethernet ports,
respectively.)
24 (The two
highest-number
ed SFP+ ports
form combo
interfaces with
their
corresponding
1/10GBASE-T
autosensing
Ethernet ports,
respectively.)
16 24 N/A
1/10G BASE-T
autosensing
Ethernet port
2 2 N/A N/A N/A
5G/2.5G/1000/1
00BASE-T
autosensing
Ethernet port
N/A N/A N/A N/A 24
Expansion slot N/A N/A
1, on the rear
panel
1, on the rear
panel
1, on the rear
panel
Power module
slot
2, on the rear
panel
2, on the rear
panel
2, on the rear
panel
2, on the rear
panel
2, on the rear
panel
Input voltage
PSR75-12A (not supported on S6520X-26MC-SI):
AC input
{ Rated voltage range: 100 to 240 VAC @ 50/60 Hz
