62
Removable power modules
Table 15 Removable power modules
Power module Specifications Reference
PSR75-12A
• AC input
{ Rated voltage range: 100 to 240 VAC @ 50/60 Hz
{ Max voltage range: 90 to 290 VAC @ 47 to 63 Hz
{ Max output power: 75 W
• High-voltage DC input:
{ Rated voltage range: 240 VDC
{ Max voltage range: 180 to 320 VDC
{ Max output power: 75 W
H3C PSR75-12A Power
Module User Manual
PSR150-A1
• Rated input voltage range: 100 to 240 VAC @ 50/60
Hz
• Max input voltage range: 90 to 264 VAC @ 47 to 63
Hz
• Max output power: 150 W
H3C PSR150-A &
PSR150-D Series Power
Modules User Manual
PSR150-D1
• Rated input voltage range: –48 to –60 VDC
• Max input voltage range: –36 to –72 VDC
• Max output power: 150 W
PSR360-56A
• Rated input voltage range: 100 to 240 VAC @ 50/60
Hz
• Max input voltage range: 90 to 264 VAC @ 47 to 63
Hz
• Max output power: 360 W
H3C PSR360-56A Series
Power Module User
Manual
PSR720-56A
• Rated input voltage range: 100 to 240 VAC @ 50/60
Hz
• Max input voltage range: 90 to 264 VAC @ 47 to 63
Hz
• Max output power: 720 W
H3C PSR720-56A Series
Power Module User
Manual
PSR1110-56A
• Rated input voltage range: 115 to 240 VAC @ 50/60
Hz
• Max input voltage range: 102.5 to 264 VAC @ 47 to
63 Hz
• Max output power: 1110 W
H3C PSR1110-56A Series
Power Module User
Manual
PSR560-56D
• Rated input voltage range: –48 to –60 VDC
• Max input voltage range: –36 to –72 VDC
• Max output power: 560 W
H3C PSR560-56D Series
Power Module User
Manual
NOTE:
The PSR1110-56A power module, including the handle, adds 64 mm (2.52 in) to the chassis depth.
Removable fan trays
Table 16 Fan tray specifications
Fan tray model Item Specifications
LSPM1FANSB (from the
Fans
One 40 × 40 × 28 mm (1.57 × 1.57 × 1.10 in)
