77
Table 36 Power module status LED description
LED mark Status Description
PWR1/PWR2
Steady green
A power module is installed in the power module slot, and the power
module is outputting power correctly.
Steady yellow
A power module is installed in the power module slot, but the power
module has failed or no power is input to the power module.
Off No power module is installed in the power module slot.
Mode LED
To show more information about the switch through the port LEDs, the switch provides a mode LED
(MODE) to indicate the type of information that the port LEDs are showing.
You can use the mode button to change the indication of the mode LED.
Table 37 Description for the mode LED
LED mark Status Description
MODE
Steady green The port LEDs indicate port rates.
Flashing yellow
The port LEDs indicates the IRF member ID
of the switch. For example, if the LEDs for
ports 1 to 5 are steady green and the other
LEDs are off, the IRF member ID of the
switch is 5.
Management Ethernet port LED
Table 38 Management Ethernet port LED description
Management Ethernet port LED (ACT/LINK) status Description
Steady green A link is present on the port.
Flashing yellow The port is sending or receiving data.
Off No link is present on the port.
1/10GBASE-T autosensing Ethernet port LED
The S6520X-16ST-SI and S6520X-24ST-SI switches each provide a status LED for each
1/10GBASE-T autosensing Ethernet port to indicate their operating status.
Table 39 1/10GBASE-T autosensing Ethernet port LED description
1/10GBASE-T autosensing
Ethernet port LED status
Description
Steady green A link is present on the port and the port is operating at 10 Gbps.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow A link is present on the port and the port is operating at 1 Gbps.
Flashing yellow The port is sending or receiving data at 1 Gbps
