Table 43 SFP+ port LED description
MODE LED status
SFP+ port LED
status
Description
Steady green (rate
mode)
Steady green
A link is present on the port and the port is operating at 10
Gbps.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow
A link is present on the port and the port is operating at 1
Gbps.
Flashing yellow The port is sending or receiving data at 1 Gbps.
Off
• No link is present on the port.
• The mode LED operates in IRF mode.
Flashing yellow (IRF
mode)
Steady green
The port status LEDs on the switch indicate the IRF
member IDs of the switch. For example, if the LEDs for
ports 1 to 5 are steady green and the other port LEDs are
off, the IRF member ID of the switch is 5.
Expansion card status LED
The S6520X-18C-SI, S6520X-26C-SI, S6520X-26MC-SI, S6520X-26MC-UPWR-SI,
S6520X-26XC-UPWR-SI, and S6520X-54XC-UPWR-SI switches each provide an expansion slot on
the rear panel. The expansion card status LED on the front panel indicates the operating state of the
expansion card.
Table 44 Expansion card status LED description
LED mark Status Description
SLOT
Steady green The expansion card is present and is operating correctly.
Flashing yellow The switch does not support the card model, or the card has failed.
Off The expansion slot is empty.
Port status LED on an expansion card
An expansion card provides a port status LED for each port. For more information about the LEDs,
see the manual for the expansion card.
Fan tray Alarm LED
The LSPM1FANSB fan tray provides an Alarm LED.
Table 45 Fan tray alarm LED description
Status Description
On The fan tray is faulty.
Off The fan tray is operating correctly.
