57
Item S6520X-10XT-SI S6520X-16XT-SI
Ethernet port
SFP+ port 2 2
10G/5G/2.5G/10
00BASE-T
autosensing
Ethernet port
8 14
Input voltage
• Rated voltage range: 100 to 240 VAC
@ 50/60 Hz
• Max voltage range: 90 to 264 VAC @
47 to 63 Hz
• Rated voltage range: 100 to 240
VAC @ 50/60 Hz
• Max voltage range: 90 to 264 VAC
@ 47 to 63 Hz
Maximum power
consumption
(100% traffic, fan
trays at full
speed)
37.9 W 57.9 W
Typical power
consumption
(30% traffic,
tested according
to CQC)
N/A N/A
Minimum power
consumption
18 W 23 W
Maximum power
consumption
38 W 58 W
Chassis leakage
current
compliance
UL60950-1/EN60950-1/IEC60950-1/GB4943.1
Melting current of
power module
fuse
6.3 A/250 V
Operating
temperature
–5°C to +45°C (23°F to 113°F)
Operating
humidity
5% RH to 95% RH, noncondensing
Fire resistance
compliance
UL60950-1/EN60950-1/IEC60950-1/GB4943.1
Table 11 Technical specifications of PoE switches
Item S6520X-26MC-UPWR-SI S6520X-26XC-UPWR-SI S6520X-54XC-UPWR-SI
Dimensions
(H × W × D)
43.6 × 440 × 460 mm (1.72 × 17.32 × 18.11 in)
Weight ≤ 8.7 kg (19.18 lb)
Console port
• 1 × micro USB console port
• 1 × serial console port
• Only the micro USB console port is available when you connect both ports.
USB port 1
Managemen
t Ethernet
1
