11
Figure 12 Mounting brackets provided with the S9850-4C switch
(1) Cable management bracket (2) Mounting bracket
Figure 13 Mounting brackets provided with the S9850-32H switch
Figure 14 1U long slide rail and chassis rail
(1) Chassis rail (2) Long slide rail
1 2
1 2
