67
Table 20 QSFP28 copper cables available for the QSFP28 ports
QSFP28 copper cable Cable length
QSFP-100G-D-CAB-1M 1 m (3.28 ft)
QSFP-100G-D-CAB-3M 3 m (9.84 ft)
QSFP-100G-D-CAB-5M 5 m (16.40 ft)
Table 21 QSFP28 fiber cables available for the QSFP28 ports
QSFP28 fiber cable Cable length
QSFP-100G-D-AOC-7M 7 m (22.97 ft)
QSFP-100G-D-AOC-10M 10 m (32.81 ft)
QSFP-100G-D-AOC-20M 20 m (65.62 ft)
Table 22 QSFP28 to SFP28 copper cables available for the QSFP28 ports
QSFP28 to SFP28 copper cable Cable length
QSFP-100G-4SFP-25G-CAB-1M 1 m (3.28 ft)
QSFP-100G-4SFP-25G-CAB-3M 3 m (9.84 ft)
QSFP-100G-4SFP-25G-CAB-5M 5 m (16.40 ft)
Table 23 QSFP+ transceiver modules available for the QSFP28 ports
QSFP+
transceiver
module
Central
wavelength
(nm)
Connector
Fiber type
and diameter
(µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
QSFP-40G-SR
4-MM850
850
MPO
(PC-polished,
12-core)
Multi-mode,
50/125
2000 100 m (328.08 ft)
4700 150 m (492.12 ft)
QSFP-40G-CS
R4-MM850
850
MPO
(PC-polished,
12-core)
Multi-mode,
50/125
2000 300 m (984.25 ft)
4700 400 m (1312.33 ft)
QSFP-40G-LR
4-PSM1310
1310
MPO
(APC-polished,
12-core)
Single-mode,
9/125
N/A
10 km (6.21
miles)
QSFP-40G-BI
DI-SR-MM850
850 LC
Multi-mode,
50/125
2000 100 m (328.08 ft)
4700 150 m (492.12 ft)
QSFP-40G-LR
4-WDM1300
Four lanes:
• 1271
• 1291
• 1311
• 1331
LC
Single-mode,
9/125
N/A
10 km (6.21
miles)
QSFP-40G-LR
4L-WDM1300
Four lanes:
• 1271
• 1291
• 1311
• 1331
LC
Single-mode,
9/125
N/A 2 km (1.24 miles)
