H3C S6850 Series

70
25G SFP28 fiber cable Max transmission distance
SFP-25G-D-AOC-10M 10 m (32.81 ft)
SFP-25G-D-AOC-20M 20 m (65.62 ft)
NOTE:
• To connect an SFP28 port on the S6850-56HF switch to a peer interface that does not support
speed and duplex autonegotiation, you must execute the speed and duplex full commands on
both interfaces. Configure the same speed and duplex mode for the two interfaces and the speed
must be the same as that of the transceiver module or cable installed in the interface.
• An SFP28 port on the LSWM124TG2H interface module does not support speed and duplex
autonegotiation. To connect an SFP28 port on the LSWM124TG2H interface module to a peer
interface, you must execute the speed and duplex full commands on both interfaces. Configure
the same speed and duplex mode for the two interfaces and the speed must be the same as that
of the transceiver module or cable installed in the interface.
Table 30 10-GE SFP+ transceiver modules available for the SFP28 ports
10-GE SFP+
transceiver
module
Central
wavelength
(nm)
Connector
Fiber type and
diameter (µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
SFP-XG-SX-M
M850-A
850 LC
Multi-mode,
50/125
2000 300 m (984.25 ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
Multi-mode,
62.5/125
200 33 m (108.27 ft)
160 26 m (85.30 ft)
SFP-XG-LX-S
M1310
1310 LC
Single-mode,
9/125
N/A
10 km (6.21
miles)
Table 31 10-GE SFP+ copper cables available for the SFP28 ports
10-GE SFP+ copper cable Max transmission distance
LSWM1STK 0.65 m (2.13 ft)
LSWM2STK 1.2 m (3.94 ft)
LSWM3STK 3 m (9.84 ft)
LSTM1STK 5 m (16.40 ft)
Table 32 10-GE SFP+ fiber cables available for the SFP28 ports
10-GE SFP+ fiber cable Max transmission distance
SFP-XG-D-AOC-7M 7 m (22.97 ft)
SFP-XG-D-AOC-10M 10 m (32.81 ft)
SFP-XG-D-AOC-20M 20 m (65.62 ft)
