336LE008146B
Navigation and menus
3.7 Advanced Protection menu
Content of the CURRENT submenu
Text Unit Description
I
1 A RMS current I1 on L1
2 A RMS current I2 on L2
3 A RMS current I3 on L3
N A RMS current IN on neutral
MAX A Maximum current between I1, I2, I3 and IN
IG
IG A RMS current calculated at earth
MAX A Last maximum RMS current value calculated at earth
I max
1 A Maximum RMS current I1 on L1
2 A Maximum RMS current I2 on L2
3 A Maximum RMS current I3 on L3
N A Maximum RMS current on neutral
I min
1 A Minimum RMS current I1 on L1
2 A Minimum RMS current I2 on L2
3 A Minimum RMS current I3 on L3
N A Minimum RMS current on neutral IN
I avg
I A Arithmetic mean current of I1, I2 and I3
MAX A Last maximum of arithmetic mean current
MIN A Last minimum of arithmetic mean current
I unb
1 % current unbalance between I1 and the arithmetic mean
2 % current unbalance between I2 and the arithmetic mean
3 % current unbalance between I3 and the arithmetic mean
MAX % maximum unbalance between Inba1, Inba2 and Inba3
max
unb
I % Last maximum of unbalanced current
Content of the FREQUENCY submenu
Text Unit Description
FREQUENCY Hz
QUADRANT - power quadrant
PHASE SEQ.
1, 2, 3 - Direct
1, 3, 2 - Reverse
