hager hw+ User Manual

34 6LE008146B
Navigation and menus
3.7 Advanced Protection menu
Content of the POWER submenu
Text Unit Description
P
1 kW Active power on phase L1
2 kW Active power on phase L2
3 kW Active power on phase L3
tot kW Total active power
Q
1 kvar Reactive power on phase L1
2 kvar Reactive power on phase L2
3 kvar Reactive power on phase L3
tot kvar Total reactive power
S
1 kVA Apparent power on phase L1
2 kVA Apparent power on phase L2
3 kVA Apparent power on phase L3
tot kVA Total apparent power
P max
1 kW Last maximum active power on phase L1
2 kW Last maximum active power on phase L2
3 kW Last maximum active power on phase L3
tot kW Total maximum active power
Q max
1 kvar Last maximum reactive power on phase L1
2 kvar Last maximum reactive power on phase L2
3 kvar Last maximum reactive power on phase L3
tot kvar Total maximum reactive power
S max
1 kVA maximum apparent power on phase L1
2 kVA maximum apparent power on phase L2
3 kVA maximum apparent power on phase L3
tot kVA maximum total apparent power
Text Unit Description
Ea
tot
IN kWh total active energy imported (consumed)
OUT kWh total active energy exported (produced)
Er
tot
IN kvarh total reactive energy imported (consumed)
OUT kvarh total reactive energy exported (produced)
Ea
part
IN kWh total active energy exported (consumed) (partial meter)
OUT kWh total active energy exported (produced) (partial meter)
Es
kVAh Apparent energy
Content of the ENERGY submenu
