Navigation and menus
3.7 Advanced Protection menu
Content of the DEMAND submenu
Content of the POWER FACTOR submenu
Text Unit Description
I
1 A current demand on phase L1
2 A current demand on phase L2
3 A current demand on phase L3
N A neutral current demand
I avg
I A average current demand
I peak
1 A peak current demand on phase 1
2 A peak current demand on phase 2
3 A peak current demand on phase 3
N A peak current demand on neutral N
AVG
peak
I A Average peak current demand
PQS
P kW total active power demand
Q kvar total reactive power demand
S kVA total apparent power demand
PQS
peak
P kW total peak active power demand
Q kvar total peak reactive power demand
S kVA total peak apparent power demand
Text Unit Description
PF
1 - Power factor on phase 1
2 - Power factor on phase 2
3 - Power factor on phase 3
tot - Total power factor
Cos
φ 1
- Fundamental power factor on phase 1
φ 2
- Fundamental power factor on phase 2
φ 3
- Fundamental power factor on phase 3
φ tot
- Total fundamental power factor
