38 6LE008146B
Navigation and menus
3.9 Alarms menu
Step/Action Button Display
4 Activate the change of the
STATUS parameter.
ALARM 1
<
1600A
I1
Curr
Over
THRESHOLD
OPTION 1
TYPE
OPTION 2
OSTATUS
5 Change the STATUS
parameter to On and
confirm.
ALARM 1
<
1600A
I1
Curr
Over
THRESHOLD
OPTION 1
TYPE
OPTION 2
OnSTATUS
6 Choose the type of
measurement to monitor
and confirm the change
(same procedure as stages
4 and 5).
The parameters OPTION
1 and OPTION 2 change
automatically according
to the parameter TYPE
chosen.
ALARM 1
<
On
1600A
I1
Curr
Over
STATUS
THRESHOLD
OPTION 1
TYPE
OPTION 2
7 Move on to the next
parameter and adjust all
of the alarm parameters in
the same way.
ALARM 1
<
On
1600A
I1
Over
STATUS
THRESHOLD
OPTION 1
OPTION 2
Curr
TYPE
8 When all the parameters
have been defined, press
the left button.
ALARM 1
<
Over
10S
OPTION 2
DROPOUT DEL
TIME
DROPOUT VAL
260.0V
30S
245.0V
THRESHOLD
