Navigation and menus
3.9 Alarms menu
Type Text Description
Power
STATUS O, On
OPTION 1
Pd1, Pd2, Pd3, Pdtot, Pr1, Pr2, Pr3, Prtot, Qd1, Qd2, Qd3, Qdtot, Qr1,
Qr2, Qr3, Qrtot, S1, S2, S3, Stot
OPTION 2 Under or over
THRESHOLD depending on the type of power
TIME 1 to 3000 s in increments of 1 s
DROPOUT
VAL.
depending on the type of power
DROPOUT
DEL
1 to 3000 s in increments of 1 s
Power Factor
STATUS O, On
OPTION 1
PF1, PF2, PF3, PFtot, Cosφ1, Cosφ2, Cosφ3, Cosφtot
OPTION 2 Inductive or capacitive
THRESHOLD 0.00 to 0.99 with steps of 0.01
TIME 1 to 3000 s in increments of 1 s
DROPOUT
VAL
0.00 to 0.99 with steps of 0.01
DROPOUT
DEL
1 to 3000 s in increments of 1 s
THD
STATUS O, On
OPTION 1 I1,I2, I3,IN, V1N, V2N, V3N, U12, U23, U31
OPTION 2 Under or over
THRESHOLD 0 to 1000% in increments of 0.1%
TIME 1 to 3000 s in increments of 1 s
DROPOUT
VAL
0 to 1000% in increments of 0.1%
DROPOUT
DEL
1 to 3000 s in increments of 1 s
Frequency
STATUS O, On
OPTION 1 F
OPTION 2 Under or over
THRESHOLD 45.0 to 65.0 Hz with steps of 0.01
TIME 1 to 3000 s in increments of 1 s
DROPOUT
VAL
45.0 to 65.0 Hz with steps of 0.01
DROPOUT
DEL
1 to 3000 s in increments of 1 s
Demand
STATUS O, On
OPTION 1 I1, I2, I3, IN, IAvg, P, Q, S
OPTION 2 Under or over
THRESHOLD depending on the type of value
TIME 1 to 3000 s in increments of 1 s
DROPOUT
VAL
depending on the type of value
DROPOUT
DEL
1 to 3000 s in increments of 1 s
Quadrant
STATUS O, On
OPTION 1 Quadrant 1 to 4
TIME 1 to 3000 s in increments of 1 s
DROPOUT
DEL
1 to 3000 s in increments of 1 s
Phase Seq.
STATUS O, On
OPTION 1 1,2,3 or 1,3,2
TIME 1 to 3000 s in increments of 1 s
DROPOUT
DEL
1 to 3000 s in increments of 1 s
