hager hw+ User Manual

8 6LE008146B
The sentinel Energy trip unit
2.1 General description
The sentinel Energy trip unit is compatible with the following types of cable-based and
wireless communication.
In local communication:
Bluetooth Low Energy connection to a smartphone running the Hager Power touch
application.
Through a network cable connection:
Ethernet communication network with the Modbus-TCP protocol.
Serial link communication network with the Modbus-RTU protocol.
The following diagram shows how the sentinel Energy trip unit communicates with external
media.
HTD210H
hw+ communication system
1
HTD210H panel display (for a single circuit breaker)
2
Web page to access the product documentation
3
Modbus-RTU or Modbus-TCP communication module
4
Hager Power setup application via USB connection
5
Hager Power touch application via Bluetooth connection
1
3
2
4
5
