Measurement functions
6.7 Measuring averaged values over an interval
Averaged values maximum
For each averaged value period calculated, the maximum value over the time interval is stored.
The maximum values can be reset to zero from the sentinel Energy display, the panel display
or the Hager Power setup software.
The exhaustive list of current and power demand values calculated according to the 3-pole or
4-pole version and the visualisation interface, is given in the table below:
The type of integration interval and the duration of the interval T are configurable on the
sentinel Energy display, the panel display and the Hager Power setup software.
N.B.
The Qtot Dmd, Stot Dmd, Max Q1 Dmd, Max Q2 Dmd, Max Q3 Dmd, Max Qtot Dmd and Max
Stot Dmd values depend on the arithmetic or vector summation convention for reactive and
apparent power (see §6.13 – Setting the reactive and apparent power calculation convention).
Electrical variable Symbol 3-pole
version
4-pole
version
sentinel
Energy
display
Panel
display
Hager
Power
touch
Phase current demand I1 Dmd, I2 Dmd,
I3 Dmd
■ ■ ■
-
■
Neutral current demand IN Dmd
-
■ ■
-
■
average current demand Iavg Dmd
■ ■ ■
-
■
Active power demand per
phase
P1 Dmd,
P2 Dmd, P3 Dmd
-
■
-
■ ■
total active power demand Ptot Dmd
■ ■ ■ ■ ■
Reactive power demand
per phase
Q1 Dmd,
Q2 Dmd, Q3
Dmd
-
■
-
■ ■
Total reactive power
demand
Qtot Dmd
■ ■ ■ ■ ■
Apparent power demand
per phase
S1 Dmd,
S2Dmd, S3 Dmd
-
■
-
■ ■
Total apparent power
demand
Stot DSmd
■ ■ ■ ■ ■
Peak current demand per
phase
Max I1 Dmd,
Max I2 Dmd,
Max I3 Dmd
■ ■ ■
-
■
Neutral peak current
demand
Max IN Dmd
-
■ ■
-
■
Average peak current
demand
Max Iavg Dmd
■ ■ ■
-
■
Active peak power demand
per phase
Max P1 Dmd,
Max P2 Dmd,
Max P3 Dmd
-
■
-
■ ■
Total active peak power
demand
Max Ptot Dmd
■ ■ ■ ■ ■
Reactive peak power de-
mand per phase
Max Q1 Dmd,
Max Q2 Dmd,
Max Q3 Dmd
-
■
-
■ ■
Total reactive peak power
demand
Max Qtot Dmd
■ ■ ■ ■ ■
Apparent peak power
demand per phase
Max S1 Dmd,
Max S2 Dmd,
Max S3 Dmd
-
■
-
■ ■
Total apparent peak power
demand
Max Stot DSmd
■ ■ ■ ■ ■
