Hammer A3-41 - Machine Specifications; Drive Motor; Chip Extraction Requirements; Operation and Storage Conditions

15
Planer-Thicknesser
A3-26 / A3-31 / A3-41
*
)
S6 = 10 minute operation under load and intermittent service; 40% = relative operating factor, i.e. the motor may be run at the
nominal capacity for 4 minutes and afterwards must run idle for 6 minutes.
4.6 Particle emission
The machine was tested for particle emissions according
to DIN 33893. The Wood Authority ascertained,
according to the “Principles for Testing Particle
Emissions” (workplace-related particle concentrations) of
woodworking machines, that the particle emission values
for this machine are notably below the currently valid
atmospheric limit of 2.0 mg/m³. This is certified by the
blue label “BG Wood Particle Tested”.
4.5 Operation and storage conditions
Operating/room temperature +10° to +40° C
Storage temperature –10° to +50 °C
4.3 Drive motor
4.4 Chip extraction
The actual values can be found on the data plate.
Attention! Risk of material damage!
Only operate the machine in ambient temperatures from +10° to +40° C.
If the instructions are not followed, damage may occur during storage.
Technical specifications
Alternating-current motor Three-phase current motor
Motor voltage 1x 230 V 3x 400 V
Motor frequency 50/60 Hz 50/60 Hz
Motor power A3-26 S6-40 %
*
)
1,9 kW –
Motor power A3-31 S6-40 %
*
)
3,0 kW 3,0 kW
Motor power A3-41 S6-40 %
*
)
3,0 kW 4,0 kW
System of protection IP 55 IP 55
A3- 26 A3-31 / A3-41 Drilling unit
Extractor port diameter 100 mm 120 mm 120 mm
Air speed 20 m/s 20 m/s 20 m/s
Vacuum, min. 740 Pa 740 Pa 855 Pa
Volume flow, min. (at 20 m/s) 565 m³/h 814 m³/h 814 m³/h
