Planer-Thicknesser
A3-26 / A3-31 / A3-41
4.10 Thicknesser unit
4.11 Drilling unit
*
)
Measured from the middle of the cutterblock/drilling tool and the front edge of the drilling chuck guard.
A3-26 A3-31 A3-41
Thicknessing width 254 mm 304 mm 404 mm
Thicknesser table length 540 mm 540 mm 600 mm
Thicknessing height, min./max. 4/225 mm 4/225 mm 4/225 mm
Feeder 6,5 m/min 6,5 m/min 6,5 m/min
2-jaw drilling chuck 1–16 mm
Mortising table
Height adjustment
*
)
135 mm
Longitudinal adjustment
*
)
200 mm
Depth adjustment
*
)
130 mm
4.9 Planer unit
A3-26 A3-31 A3-41
Maximum depth of cut 4 mm 4 mm 4 mm
Surface planing width 260 mm 310 mm 410 mm
Planer table length 540 mm 628/730 mm 880 mm
Total planer table length 1120 mm 1400 mm 1800 mm
Length of surface planer fence 150 x 750 mm 150 x 1100 mm 150 x 1100 mm
Planer fence, tiltable from 90° to -45°
4.8 Cutterblock
Cutterblock diameter (knife flight)-Ø 72 mm
Number of knives 3
Speed 50/60 Hz 5000/6000 min
-1
Note:
The maximum depth of cut is directly related to the following factors:
• Panel width Panel intensity
• Type of wood (hardwood or softwood
• Wood dampness
• Feed rate
• Planer knives (SS, HS, HW)
• The motor power of your machine
Technical specifications
