*#1
:-%
Owners Manual
122
MIDI TEMPLATES
MIDI TEMPLATES
Template Basic Two Manual Pedal KBD
Messages MIDI IN
Sequence Lower Pedal
Local Control
On On On
NRPN
On On On
Program Change
On On On
Drawbar Registration
On On On
Transmit Channel Tx. Upper
111
Tx. Lower
222
Tx. Pedal
333
Rx. Upper
1 1 (disregarded, off ) 1 (disregarded, off )
Rx. Lower
2 2 (disregarded, omni) 2 (disregarded, off )
Rx. Pedal
3 3 (disregarded, off ) 3 (disregarded, omni)
External Zone
Off Off Off
Comments
Use this template to record/
play the performance only on
this unit with the external se-
quencer.
Use this template to play the
LOWER keyboard connecting
to the MIDI IN jack.
Use this template to play the
PEDAL keyboard connecting
to the MIDI IN jack.
Template 3KBD Use Ex. Zone Use Ex. w/2Man
Messages MIDI IN
Low + Ped Sequence Lower
Local Control
On On On
NRPN
On On On
Program Change
On On On
Drawbar Registration
On On On
Transmit Channel Tx. Upper
1O Off
Tx. Lower
2O Off
Tx. Pedal
3O Off
Rx. Upper
1 1 1 (disregarded, off )
Rx. Lower
2 2 2 (disregarded, omni)
Rx. Pedal
3 3 3 (disregarded, off )
External Zone
Off On On
Comments
Use this template to play the
LOWER and PEDAL key-
boards merging and connect-
ing to the MIDI IN jack.
Use this template to play only
this keyboard and control the
MIDI equipment connected to
the MIDI OUT jack with the
External Zones.
Use this template to play this
keyboard and the LOWER
keyboard connected to the
MIDI IN jack and control the
MIDI equipment connected to
the MIDI OUT jack with the
External Zone.
Template Use Ex. w/PK Use Ex. w/3KBD
Messages MIDI IN
Pedal Low + Ped
Local Control
On On
NRPN
On On
Program Change
On On
Drawbar Registration
On On
Transmit Channel Tx. Upper
Off Off
Tx. Lower
Off Off
Tx. Pedal
Off Off
Rx. Upper
1 (disregarded, off )1
Rx. Lower
2 (disregarded, off )2
Rx. Pedal
3 (disregarded, omni) 3
External Zone
On On
Comments
Use this template to play this
keyboard and the Pedal key-
board connected to the MIDI
IN jack and control the MIDI
equipment connected to the
MIDI OUT jack with the Ex-
ternal Zone.
Use this template to play the
merged LOWER and PEDAL
keyboards connecting to the
MIDI IN jack and control the
MIDI equipment connected to
the MIDI OUT jack with the
External Zone.
