*#1
:-%
Owner’s Manual
74
DAMPER
⓮ DAMPER - UPPER (G)
⓯ DAMPER - LOWER (G)
⓰ DAMPER - PEDAL (G)
Assigns the DAMPER to the various divisions of the this keyboard.
DISPLAY
⓱ DISPLAY - SHORT CUT (G)
Sets the short cut waiting time.
e setting range is 0 to 2 seconds. At NO the short cut feature is disabled.
⓲ DISPLAY - TIME OUT (G)
Sets the time for returning to the previous mode from the mode displayed by the
short cut operation.
e setting range is 4 to 16 seconds. At NO the screen will not return to the previ-
ous mode.
⓳ DISPLAY - POP UP (G)
Sets the interval at which the Pop Up is displayed when you move the [OVER-
DRIVE] knob.
e setting range is 0.5 to 2 seconds. At NO no Pop Up is displayed.
KEYBOARD
⓴ SOUNDING POINT (S)
Set the sounding point of the built-in keyboard is played.
DEEP All the section sounds on the deep point in the stroke.
AUTO The organ sound at the shallow point when striking the keys lightly, it makes a very lively
direct way of playing possible, But when the parameter “Percussion - Velocity” (P. 76 #6) is
used the sounding point is always deep.
DAMPER
Or “Sustain” pedal-analogous to the RIGHT pedal
on a piano. Sounds are held when this pedal is
depressed. Called “Damper” due to the fact that
when the pedal was depressed on a piano, the
mechanism that muted or “damped” the strings
was raised, allowing the piano strings to ring free.
CONTROL - continued
NOTE: The parameter with (P) indicated is a
patch parameter, and is recorded to
each patch. (G) indicates “global param-
eter”, (S) indicates “system parameter”,
which is recorded upon being set, and
is common with each patch.
❶ ❷❸
❹❺ ❻❼❽ ❾❿
⓬⓭
⓮⓯⓰
⓱⓲ ⓳
⓴
⓫
To Next Page
