Hammond XK-1c User Manual

129
Appendix
Category Parameter NRPN SysEx Address SysEx
Length
Data Patch Load
LSB
(62)
MSB
(63)
MSB to LSB
Percussion
Percussion On
08 00 00 08 00 01
00, 01 (Off /On) DRAWB
 ird On
08 01 00 08 01 01
00, 01 (Off /On)
Decay Fast
08 02 00 08 02 01
00, 01 (Off /On)
Volume Soft
08 03 00 08 03 01
00, 01 (Off /On)
Level On Soft
08 04 00 08 04 01
00 - 0F (1 - 16)
Level On Normal
08 05 00 08 05 01
00 - 0F (1 - 16)
Decay Fast
08 06 00 08 06 01
00 - 09 (1 - 9, Cont)
Decay Slow
08 07 00 08 07 01
00 - 09 (1 - 9, Cont)
Touch
08 08 00 08 08 01
00, 01 (Off /On)
Velocity
08 09 00 08 09 01
00, 01 (Off /On)
Key Track
08 0A 00 08 0A 01
00, 01 (Off /On)
Drawbar 1´ Cancel
08 0B 00 08 0B 01
00, 01 (Off /On)
Drawbar Level
08 0C 00 08 0C 01
00, 01 (0, -3dB)
Lower & Upper
Organ section
Organ Type
20 00 00 20 00 01
00 - 05
00: B-Type 1
01: B-Type 2
02: Mellow
03: Vx
04: Farf
05: Pipe
DRAWB
Key Click Attack
20 01 00 20 01 01
00 - 0F (0 - 15)
Key Click Release
20 02 00 20 02 01
00 - 0F (0 - 15)
Fold Back Lo
20 03 00 20 03 01
00 - 0C (C1 - C2)
Fold Back Hi
20 04 00 20 04 01
2B - 30 (G4 - C5)
Key Click LPF
20 05 00 20 05 01
00 - 7F (0 - 127)
Custom TW B-Type 1
20 06 00 20 06 01
00 - 04 (1 - 5)
Custom TW B-Type 2
20 07 00 20 07 01
00 - 04 (1 - 5)
Custom TW Mellow
20 08 00 20 08 01
00 - 04 (1 - 5)
Octerve Shift Upper
20 09 00 20 09 01
3E - 40 - 42 (-2 - 0 - +2)
Key Range Lo Upper
20 0A 00 20 0A 01
24 - 60 (MIDI note number)
Key Range Hi Upper
20 0B 00 20 0B 01
24 - 60 (MIDI note number)
Octerve Shift Lower
20 0C 00 20 0C 01
3E - 40 - 42 (-2 - 0 - +2)
Key Range Lo Lower
20 0D 00 20 0D 01
24 - 60 (MIDI note number)
Key Range Hi Lower
20 0E 00 20 0E 01
24 - 60 (MIDI note number)
Upper
Registration
16´
-- -- 01 01 00 01
00 - 08 (0 - 8) UPPER
5 1/3´
-- -- 01 01 01 01
00 - 08 (0 - 8)
8´
-- -- 01 01 02 01
00 - 08 (0 - 8)
4´
-- -- 01 01 03 01
00 - 08 (0 - 8)
2 2/3´
-- -- 01 01 04 01
00 - 08 (0 - 8)
2´
-- -- 01 01 05 01
00 - 08 (0 - 8)
1 3/5´
-- -- 01 01 06 01
00 - 08 (0 - 8)
1 1/3´
-- -- 01 01 07 01
00 - 08 (0 - 8)
1´
-- -- 01 01 08 01
00 - 08 (0 - 8)
Lower
Registration
16
-- -- 01 02 00 01
00 - 08 (0 - 8) L/P
5 1/3´
-- -- 01 02 01 01
00 - 08 (0 - 8)
8´
-- -- 01 02 02 01
00 - 08 (0 - 8)
4´
-- -- 01 02 03 01
00 - 08 (0 - 8)
2 2/3´
-- -- 01 02 04 01
00 - 08 (0 - 8)
2´
-- -- 01 02 05 01
00 - 08 (0 - 8)
1 3/5´
-- -- 01 02 06 01
00 - 08 (0 - 8)
1 1/3´
-- -- 01 02 07 01
00 - 08 (0 - 8)
1´
-- -- 01 02 08 01
00 - 08 (0 - 8)
