Spare parts | 11
Trophy
4.2 Overview exploded views
Pos Description Page
01 Front frame, front fork and front wheel Trophy 3W 12
02 Front frame, front suspension and front wheels Trophy 4W 13
03 Rear frame, drive unit and rear wheels 14
04 Steering column, mirror and basket 16
05a Console, printed circuit board and throttle control for original electronics (ID-no < QT02400) 17
05b Console, printed circuit board and throttle control for advanced electronics (ID-no > QT02400) 19
06a Wiring, electronics and batteries for original electronics (ID-no < QT02400) 21
06b Wiring, electronics and batteries for advanced electronics (ID-no > QT02400) 22
07 Seat and seat post 23
08 Covers Trophy 3W 24
09 Covers Trophy 4W 25
10a Cabling for original electronics (ID-no < QT02400) 26
10b Cabling for advanced electronics (ID-no > QT02400) 27
Options 28
