Technical product information | 77Trophy Technical product information | 77
Operating force
Operating handle < 60 N
Parking brake < 60 N
Electronic switches < 13.5 [N]
Connecting the charger plug < 60 [N]
Technical specifi cations for wheels
Front wheel diameter (3W) mm (inches) 320 x 60 (12.5 x 2.25)
Front wheel diameter (4W) mm (inches) 320 x 60 (12.5 x 2.25)
Rear wheel diameter mm (inches) 410 x 80 (16.1 x 3.1)
Tyre pressure 4W, front wheel bar (psi) 2,5 (36.3)
Tyre pressure 4W, rear wheel bar (psi) 2,5 (36.3)
Tyre pressure 3W, front wheel bar (psi) 2,5 (36.3)
Tyre pressure 3W, rear wheel bar (psi) 2,5 (36.3)
Batteries
Maximum dimensions of batteries (lxbxh) mm (inches)
334 x 178 x 253
(13.1 x 7 x 10)
Max. battery capacity C20 Ah 86
Max. battery capacity C5 Ah 72
Maximum permissible charging voltage Voltage 13.6
Maximum permitted charging current Ampère 12 RMS
* Excluding seat and tiller folded down
** range dependent on user weight, condition of tyres, type of terrain, condition of battery and weather conditions with 80 Ah (C20)
7.3 Driving programs
The driving programs for Handicare products can be found on our FTP server.
Log on to the FTP server:
• Open internet explorer
• Go to ftp://mobilityftp.handicare.com
• Enter user name and password
User name: dealer@mobilityftp.handicare.com
Password: dealer
• You will be logged on
• Select your wheelchair and the appropriate controller
• Click the fi le to download
