7.5 Controller settings PG Drives S-Drive 120A
Trophy S-drive 120, 15 km/h
Speed Settings Fast Slow Factory Settings Max Min
Forward Acceleration (0,1 Seconds) 35 35 Acceleration (0,1 Seconds) 100 1
Forward Deceleration (0,1 Seconds) 13 13 Deceleration (0,1 Seconds) 100 1
Reverse Acceleration (0,1 Seconds) 40 40 Forward Speed (%) 100 0
Reverse Deceleration (0,1 Seconds) 25 25 Reverse Speed (%) 100 0
Max Forward Speed (%) 100 100
Min Forward Speed (%) 10 10 Throttle Settings
Max Reverse Speed (%) 40 40 Throttle Type 1
Min Reverse Speed (%) 5 5 Throttle Deadband (%) 15
Speed Limit Pot Enabled On Throttle Gain (%) 140
Throttle Operated at Power-up 2 0 = Drive,
1 = Inhibit,
2 = Trip
Operation Settings
Sleep timer (minutes) 0
Throttle Invert Yes Throttle Reference Test On
Iso Test Resistor Off
Battery Settings
Low battery Flash Level (Bars) 0 Motor Settings
Cable Resistance (milli-Ohms 50 Current Limit Max (Amps) 110
Calibration Factor 100 Boost Drive Current (Amps) 120
Low Battery Alarm Off Boost Drive Time (Seconds) 10
Current Foldback Threshold (Amps) 110
Inhibit Settings Curerent Foldback Time (Seconds) 15
Inhibit 1: Mode 1 Current Foldback Level (%) 50
Inhibit 1: Operation Latching Motor Cooling Time (Seconds) 120
Inhibit 1: Speed (%) 0 Current Foldback Temperature (Deg C) 80
Inhibit 2: Mode 1 Current Limit Min (Amps) 18
Inhibit 2: Operation Latching Motor Compensation (milli Ohms) 20
Inhibit 2: Speed (%) 0 Anti Rollback Level 12
Inhibit 3: Mode 1 Pull-away Delay (centi-Seconds) 0
Inhibit 3: Operation Latching Slope Factor 1275
Inhibit 3: Speed (%) 0 Anti Rollback Velocity 0
Aux Output: Mode 0
General Settings
Soft Stop On
Brake Time (milli-seconds) 1500
Output Voltage (Volts) 24
Status Output Type 0 (0 = Trucharge, 1 = LED, 2 = Analogue)
Diagnostic Flash Sequence 2
Reverse Alarm Off
Pulsed Reverse Alarm Off
Diagnostic Alarm Off
Brake Disconnected Alarm Off
Brake Fault Detect On
Brake Light On
Freewheel Speed Limit 35
Freewheel Time Out (0,01 Seconds) 20
Freewheel Enable Disable
Inhibit 2 Horn Input Enable Off
