Trophy76 | Technical product information
7 Technical product information
7.1 CE Declaration and standards
This product complies with the regulations of the Medical Devices Directive and therefore
bears the CE mark.
Standard Defi nition/description Weight test dummy
EU guideline 93/42 EEC Applicable as mentioned in Appendix 1 N/A
NEN-EN 12182 (1999)
The requirements from EN12182 as mentioned in NEN-EN 12184 (1999):
Technical aids for the handicapped – General requirements and test methods
October 1997
160 kg
NEN-EN 12184 (1999)
Class C
Electric wheelchairs, scooters and accompanying battery chargers –
Requirements and test methods 2009
160 kg
ISO 7176-8
Requirements and test methods for static, impact and fatigue strengths July
1998
160 kg
ISO 7176-9 Climate tests for electric wheelchairs and scooters N/A
ISO 7176-14
Requirements and test methods for control systems for electric wheelchairs
1997
N/A
ISO 7176-16 Requirements for resistance to ignition of upholstered parts May 1997 N/A
7.2 Technical specifi cations
Manufacturer Handicare
®
Model Trophy 3 wheels (3W)
Trophy 4 wheels (4W)
Maximum user weight 160 kg (25.2 stone)
Description 3W 4W
Total length mm (inches)
1400 (55.1) 1400 (55.1)
Total width mm (inches)
660 (26) 660 (26)
Minimum height* mm (inches)
760 (29.9)* 760 (29.9)*
Total weight excluding batteries kg (stones)
110 (17.3) 121 (19.1)
Total weight including batteries (80 Ah) kg (stones)
155 (24.4) 166 (26.1)
Weight of heaviest component kg (stones)
90 (14.2) 101 (15.9)
Static stability in the downward direction °
15 15
Static stability in the upward direction °
15 15
Lateral static stability °
15 15
Distance range (ISO 7176-4)** km (miles)
60 (37.3) 60 (37.3)
Dynamic stability °
11 (Alpine 14) 11 (Alpine 14)
Maximum speed forwards km/h (mph)
15 (Alpine 11)
(9.3, Alpine 6.8)
15 (Alpine 11)
(9.3, Alpine 6.8)
Back angle °
45 - 85 - 180 45 - 85 - 180
Effective seat depth mm (inches)
430 (16.9) 430 (16.9)
Effective seat width mm (inches)
500 (19.7) 500 (19.7)
Back height (excl. head rest) mm (inches)
550 (21.7) 550 (21.7)
Seat height (front edge of seat) mm (inches)
min 420 - max 550
(min 16.5 - max 21.2)
min 420 - max 550
(min 16.5 - max 21.2)
Armrest height mm (inches)
min 150 - max 340
(min 5.9 - max 13.4)
min 150 - max 340
(min 5.9 - max 13.4)
Front armrest to backrest mm (inches)
260 (10.3) 260 (10.3)
Distance between armrests mm (inches)
457 - 610 (18 - 24) 457 - 610 (18 - 24)
Turning radius (ISO 7176-5) mm (inches)
1250 (49.2) 1750
Reversing width mm (inches)
1650 (65) 1940 (76.4)
Obstacle height (max. user weight) mm (inches)
100 (3.9) 100 (3.9)
Ground clearance (max. user weight / loaded) mm (inches)
70 (2.8) 70 (2.8)
Test data
Test weight 160 kg (25.2 stone)
