Spare parts | 15
Trophy
Continued from 03 Rear frame, drive unit and rear wheels
Pos Qty Article number Description
8c 1 1015154 Rear wheel standard, grey rim and grey tyre with block profi le
8d 1 9007718 Rear wheel right side standard, grey rim and black tyre
8e 1 9007722 Rear wheel right side standard, grey rim and black tyre with block profi le
9a 2 9000548 Tyre grey rear wheel Trophy
9b 2 1015102 Tyre grey with block profi le rear wheel Trophy
9c 2 9007716 Tyre black rear wheel Trophy
9d 2 9007725 Tyre black with block profi le rear wheel Trophy
10 2 9000547 Inner tube, rear wheel Trophy
11 2 1004272 Cover white
12 2 9002006 Cover grey
13 1 9000821 Magnet plate, speed sensor
14 1 9000642 Speed sensor magnet
15 1 00000.4009 Allen bolt M8x35
16 2 00000.1703 Lock nut M10 D985
17 1 9000603 Rear spring, standard
17 1 9000683 Rear spring, heavy duty
18 1 1002243 Allen bolt M10x75
19 4 00000.4307 Hex bolt M6x12
20 1 9000256 Mounting bracket, right mud guard
21 1 9000257 Mounting bracket, left mud guard
22 2 9000689 Rubber mounting strip, transaxle
23 1 1002242 Allen bolt M10x40
24 1 9000494 Back frame
25 2 1353 Hinge bush M8
- 1 1003225 Motor brake, Egis
- 1 9003243 Motor brake, S-Drive
- 1 1012104 Motor brake for CT transaxle
- 1 1003209 Friction disk for motorbrake
- 1 1002576 Brake right for hand brake
- 1 1002577 Brake left for hand brake
- 2 9001171 Wheel hub standard
- 2 9000551 Wheel hub with drum brake
- 1 1012106 Freewheel lever for CT transaxle
- 1 1015444 Motorbrake cover Schmid
- 1 1001817 Hand brake
