Trophy70 | Service instructions 70 | Service instructions
Expand controller options for advanced electronics (ID-no > QT02400)
Function button foils on dashbord
Basic foil Advanced foil
Left throttle selection switch Yes Yes
Revers switch for foot throttle No Yes
Display menu selection switch Yes Yes
Cruise control switch No Yes
Right throttle selection switch Yes Yes
Trophy's equipped with the fi nger/hand control the basic foil will be used If the foot throttle and/or cruise control is chosen, the
advanced foil (with all icons) will be used. Be aware that the switches are always visible on the foil but not working when an
option is not selected.
Upgrade can be done via spare part options (see matrix below):
to
Right hand Left hand Foot Hand/foot Dual hand CC
Emergency
stop
from
Right hand - 0 2 2+4 1+4 5+7+8 or (9) 8
Left hand 0 - 2 2+4 1+4 5+7+8 or (9) 8
Foot 1 1 - 1+4 2x1+4 5+7+8 or (9) 8
Hand/foot 0 0 0 - 1 5+7+8 or (9) 8
Dual hand 0 0 2 2 - 5+7+8 or (9) 8
CC (only works with 8) standard 0 10 10 1 - standard
0. Only remove/replay parts
1. 1008055 Throttle potentiometer
2. 9007569 Assy foot throttle incl. assy top full option (7)
3. 9008789 Tiller PCB Basic
4. 9008791 Tiller PCB Dual control
5. 9008790 Tiller PCB Full option
6. 9007568 Assy top standard (basic foil)
7. 1012535 Assy top full option (advanced foil)
8. 9006138 Emergency stop button
9. 1016535 Full option steering wheel (includes 2x 1+5+7+8)
10. 9007499 Assy foot throttle
Since Full option steering wheel only means to exchange the complete steering wheel, this may be advisable to use always as
upgrade for Cruise Control on single hand/fi nger control.
Cruise control will only work together with the Emergency Stop Button. If this button doesn’t function or isn’t present, the scooter
will give an error and will not start. (Safety!)
