3 - Description
3.9
Map Options
Press the Legend Setup tool, and the
Legend Select screen appears. Here you can adjust
Legend Settings, clear the map.
• Clear Map
Permanently removes on-screen map from
the active field operation, but the log data
will still be exported to the USB drive.
±
WARNING! Once you clear the map, this
information cannot be retrieved.
• Load Reference
Loads a list of maps of previous operations
performed in that field. For each operation,
you can view As-Applied or Coverage
attributes; and Varieties if you are performing
a Planting operation.
Markers tab
Markers are a collection of point objects that are available on the Map Markers tab of the Mapping
Toolbox. Map markers allow you to map points on the go in order to identify specific features within a
field. Press an individual marker to indicate a Map Marker on the Map screen.
If all of the Markers that you created are not immediately visible in this screen, use the Cycle Markers
button to view more that you created.
Cycle Markers
Field tab
Field tab allows the user to setup boundaries, headlands, and topography.
Map Options
Load
Reference
Map Options
Data Guidance Boundary
Marker
Reference Rx Tile Grid
Clear Map
Top ogr ap hy
Markers
Rock
Washout
Weeds
Hole
Field
Boundary
Headlands
Topography
