4 - System setup
4.41
25. Enter Vehicle Name:
A. Press button to change name.
B. Press to confirm name.
26. Press to enter values for Antenna Offsets.
27. Vehicle Offsets:
A. Press to enter Antenna Location from
Rear Axle.
B. Select if the Antenna is In Front or
Behind the Rear Axle.
C. Press to enter Antenna Location from
the sprayers center line.
D. Select if the Antenna is to the Left or
Right of the sprayers center line.
E. Press to enter Antenna Height from
Ground.
F. Press “Steering” to continue with
Steering Type selection.
Implement Wizard: Vehicle Name
Enter Vehicle Name
Hardi Saritor
Operating Configuration Wizard: Vehicle
Select Vehicle
Offsets
Antenna Location from Rear Axle
Antenna Location from Centerline
Antenna Height from Ground
Dispensing Location from Rear Axle
Dispensing Location from Centerline
Behind
Vehicle Offsets: Hardi Saritor
Antenna
Steering
In Front
Left
Enter Distance from Vehicle References to the Antenna
Enter Location from
Rear Axle
Enter Location from
Centerline
Antenna Height from
Ground
