1-4 M-507C
Figure 1.3 - Machine Dimensions and Support Feet Locations: T-51 and T-65 Lathes
(Machine Serial Numbers DQ-111, DQ113 through DQ-116, DQ-118, DQ-119, DQ-121 and Later)
TI5886
Provide Clearance for
Door Swing
32.3
[820]
24.0
[610]
Minimum Recommended Space to Allow
Power Case Platform to be Moved to Perform
Service at the Back of the Machine.
Main Power Entrance
Main Air
Connection
(at bottom of
platform)
109.9
[2791]
24.2
[615]
51.4
[1304]
28.4
[723]
36.5
[927]
43.2
[1097]
Optional
Chip Conveyor
128.2
[3257]
77.3
[1964]
85.3
[2167]
45.3
[1151]
Lift Slot
Lift Slot
13.4 [341]
Note: Dimensions are Inches [Millimeters]
Adjustable Foot
Non-Adjustable Feet
93.3
[2370]
