Hardinge T-42 - Installing the Interlock Switch on the Rear Access Door

INSTALLING THE INTERLOCK SWITCH ON THE REAR ACCESS DOOR
For shipping purposes, the rear access door interlock switch is stowed next to the hydraulic unit
heat exchanger. Refer to Figure 1.13.
1. Using the fasteners supplied with the switch, mount the interlock switch on the access door, as
shown in Figure 1.14.
2. Close and latch the access doors.
1-12 M-507C
Figure 1.13 - Shipping Location
for Door Interlock Switch
TP8278
Interlock Switch
Shipping Location
Figure 1.14 - Interlock Switch
Mounted on Access Door
TP8279
