REMOVING THE GUARD SUPPORT BRACKETS (T-51 AND T-65 LATHES)
Remove the left and right guard support brackets, shown in Figure 1.8.
1-10 M-507C
Figure 1.8 - Guard Support Brackets
(T-51 and T-65 Lathes)
TI5852
Isometric View
of Brackets
Left Guard
Support Bracket
Right Guard
Support Bracket
