2-28 M-507C
Figure 2.38 - Shipping Tubes
Under Power Case Platform
(Components Removed for Clarity)
Shipping Tubes
TP7941
Figure 2.39 - Shipping Tubes
Attached to Machine Pedestal
Shipping Tubes
TP7940
Figure 2.40 - Power Case Platform Legs
T
U
TP7872
