Hardkernnel ODROID-C2 - Ethernet and Wifi

7 ODROID C2 USER MANUAL
XX:XX:XX:XX:XX:XX Rapoo E6700
bluez-simple-agent hci0 XX:XX:XX:XX:XX:XX
Push the Connect button again, and enter the shown pin on the
keyboard, followed by the Enter key. If no pin is shown, try 000000.
Then, type the following to trust the device and restart the bluetooth
service:
$ sudo bluez-test-device trusted XX:XX:XX:XX:XX:XX yes
$ sudo /etc/init.d/bluetooth restart
In Android, use the Bluetooth conguration screen in the Set-
tings application to connect to the bluetooth device.
Ethernet and WiFi
The Ethernet port accepts a standard CAT 5E or 6 Ethernet cable,
and is capable of up to 1GBps (1000 MB/second) transmission rate.
Typically, a working wired ethernet connection creates the eth0 inter-
face, whose details can be obtained with the following command:
odroid@odroid64:~$ ifcong eth0
eth0 Link encap:Ethernet HWaddr 00:3f:06:25:57:56
inet addr:192.168.6.33 Bcast:192.168.6.255
Mask:255.255.255.0
inet6 addr: fe77::52e:6ea:fb63:53fe/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:25817 errors:0 dropped:0 overruns:0 frame:0
TX packets:27210 errors:0 dropped:0 overruns:0 carri-
er:0
collisions:0 txqueuelen:1000
RX bytes:14685550 (14.6 MB) TX bytes:14333588 (14.3
MB)
Interrupt:40
A WiFi USB adapter, such as the ofcial Hardkernel WiFi Module
3, ts in any of the 4 USB ports. With a fully authenticated WiFi connec-
tion, the connection details can be found with the following command:
odroid@odroid64:~$ ifcong
enx00a82b000636 Link encap:Ethernet HWaddr 00:a8:2b:00:06:36
inet addr:192.168.6.160 Bcast:192.168.6.255
Mask:255.255.255.0
inet6 addr: fe80::2b6:2cef:ff50:636/64 Scope:Link
UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1
RX packets:118 errors:0 dropped:2 overruns:0 frame:0
TX packets:50 errors:0 dropped:0 overruns:0 carrier:0
collisions:0 txqueuelen:1000
RX bytes:11313 (11.3 KB) TX bytes:8948 (8.9 KB)
Chapter 1
