61 ODROID C2 USER MANUAL
can use the command-line bluetooth packet analyzer/sniffer to ana-
lyze bluetooth trafc between the ODROID-C2 and a known bluetooth
device using the following command:
$ sudo hcidump
[sudo] password for odroid:
HCI sniffer - Bluetooth packet analyzer ver 5.37
device: hci0 snap_len: 1500 lter: 0xffffffffffffffff
< HCI Command: LE Set Scan Parameters (0x08|0x000b) plen 7
type 0x01 (active)
interval 11.250ms window 11.250ms
own address: 0x00 (Public) policy: All
> HCI Event: Command Complete (0x0e) plen 4
LE Set Scan Parameters (0x08|0x000b) ncmd 1
status 0x00
< HCI Command: LE Set Scan Enable (0x08|0x000c) plen 2
value 0x01 (scanning enabled)
lter duplicates 0x01 (enabled)
> HCI Event: Command Complete (0x0e) plen 4
LE Set Scan Enable (0x08|0x000c) ncmd 1
status 0x00
< HCI Command: LE Set Scan Enable (0x08|0x000c) plen 2
value 0x00 (scanning disabled)
lter duplicates 0x00 (disabled)
> HCI Event: Command Complete (0x0e) plen 4
LE Set Scan Enable (0x08|0x000c) ncmd 1
status 0x00
< HCI Command: Inquiry (0x01|0x0001) plen 5
lap 0x9e8b33 len 4 num 0
> HCI Event: Command Status (0x0f) plen 4
Inquiry (0x01|0x0001) status 0x00 ncmd 1
> HCI Event: Extended Inquiry Result (0x2f) plen 255
bdaddr D8:B3:77:6F:E2:36 mode 1 clkoffset 0x5d2e class
0x5a020c rssi -78
Complete local name: ‘OBDII dongle’
Complete service classes: 0x1105 0x1106 0x110a 0x110c 0x1112
0x111f 0x112f 0x1200
…
Tinkering Kit
While the power-efcient C2 is a very capable system for soft-
ware development, it is also very highly suited to prototyping hardware
development. Hardkernel has developed the C Tinkering kit with nu-
merous items to get you started, as shown on the next page.
Some of the components in the Tinkering Kit include:
• Assembled T-breakout PCB - 40Pin GPIO Breakout board
• Breadboard - 630 Tie-points with dual power lanes
• 40pin Ribbon cable - IDC Flat cable 100mm
Chapter 4
