62 ODROID C2 USER MANUAL
• 40pin Male-to-Male Dupont jumper Wire 170mm
• Green/Yellow/Red 3mm LEDs – 7 each
• 2 x Photocell (CdS Light sensor), 6 x Tact Switches
• 330 Ω / 10 KΩ 1/6W resistors – 50 each
Tinkering Kit
GPIO layout for the 40-pin header on the ODROID-C2
The T-breakout board breaks-out all the pins from the 40-pin
header onto a solderless breadboard. The pins include, power, GPIO,
I2C, and ADC pins. This simplies prototyping of data acquisition and
control projects.
It is advisable to refer to the Amlogic S905 data sheet at http://
bit.ly/2bfeRFF to fully understand the GPIO designations.
The above image illustrates simplied information on layout and
the designation of the 40 pins. Use the data sheet and this information
with caution when applying voltages to the pins, to ensure compliance
Chapter 4
