Chapter 1 ProStream 9100 Overview
© 2016 Harmonic Inc. All rights reserved. 10 ProStream 9100 Release 17.5, Rev A
ProStream 9100 Physical and Power Specifications
ProStream 9100 Physical and Power Specifications
Physical Dimensions
Table 1–1: Physical Dimensions
Dimension Inches Centimeters
Height 1.75 4.45
Width 19 48.36
Total Length (front to back) 27 68.69
Depth (from rack mount fixtur
e to back of device) 25.20 64
Power Supply Specifications
ProStream 9100 is equipped with two field replaceable redundant AC/DC power supply units.
Each power supply unit easily accommodates the power consumption of a fully populated device.
When both power supply units are plugged in and connected to the mains, the power supply
units operate in current sharing mode.
Harmonic sells power supply units that have been thoroughly qualified to operate with the
ProStream 9100 device. Table 1–2 lists power specifications of a fully populated unit together with
the Harmonic part numbers for the qualified power supply modules. Use these part numbers to
order your power supply modules.
For installation details, see Overcurrent Protection.
For cabling details, see Connecting the Power.
Environmental Specifications
The following table lists the environmental specifications for ProStream 9100.
Table 1–2: Power Supply Units Specifications
PS Type Input Voltage Range
Input Line
Frequency
Comments
AC 100 to 240 VAC 47 to 63 Hz Input voltage range is auto ranging
DC 40 to 60 VDC N/A Nominal input is -48VDC
Table 1–3: Environmental Specifications
Parameter Description
Temperature Operating 0 to 50 °C (32 to 122 °F)
Storage –20 to 80 °C (–4 to 176 °F)
Ventilation Ventilation When fans operate at full speed, air flow through the
device is at least 2.098m³/min (74.1 CFM) per
ProStream 9100 unit
