Chapter 1 ProStream 9100 Overview
© 2016 Harmonic Inc. All rights reserved. 12 ProStream 9100 Release 17.5, Rev A
Front Panel
Front Panel
Table 1-5: ProStream 9100 Front Panel
Item Feature
1 Front bezel
2 Ethernet service port (for debugging purposes only)
3 LEDs
4 Control Panel
5 Front Panel Latch
NOTE: Cooling fans are mounted on the rear of the front panel. See Cooling Fans.
The following illustration shows a detailed view of the front panel without any optional modules.
