Chapter 1 ProStream 9100 Overview
© 2016 Harmonic Inc. All rights reserved. 21 ProStream 9100 Release 17.5, Rev A
Back Panel
NOTE: To be eligible for support by Harmonic, use qualified SFPs only.
An optical SFP has two LC sockets, Receive(Rx) and Transmit(Tx). Use Multimode or Singlemode
fiber optics to connect your Gigabit Ethernet switch to the Rx socket. If bi-directional topology is
used, connect the Tx socket back to the switch.
8VSB Modulation Card
The 8VSB modulation card is an RF input module that enables the reception of ATSC terrestrial
TV. It receives four independent ATSC 8VSB signals on the inputs and outputs from four MPEG-2
Transport Streams.
NOTE: The four inputs are enabled by optional firmware licenses.
8VSB Modulation Card Specifications
Table 1–14 provides the specifications for the RF module.
Table 1–15: 1Giga SFP Modules
Fiber/Cable Type
Connector
Type
Wave Length
Max. Cable/
Fiber Length
Qualified Finisar SFP
Model Part Num.
Multimode fiber 2 x LC 850 nm 550m FTLF8519P2BNL
Singlemode fiber 2 x LC 1310 nm 10 km FTLF1319P1BTL
Singlemode fiber 2 x LC 1550 nm 70 km FTLF1621P1BCL
Shielded and
grounded CAT-6 or
CAT-7
1 x RJ-45 N/A 100m FCLF-8521-3
Table 1–16: 10Giga SFP+ Module
Fiber/Cable Type
Connector
Type
Wave
Length
Max. Cable/
Fiber Length
Qualified Finisar SFP
Model Part Num.
Multimode fiber 2 x LC 850nm 300m FTLX8571D3BCV
Table 1–17: RF Module Specifications
Feature Support
Connectors 4x Type F, 75 per IEC 60169-24
Modulation 8–VSB (ATSC compliant)
