HMX6803+ and OP+HMX+ Installation and Operation Manual 9
Copyright © 2009, Harris Corporation
Chapter 1: Introduction
25 162A10019X (DB9.5) RS232_GND
(DB9)
SERIAL Black N/A
25 BNC GND AES OUT 4
GND
AES OUT 4 Blue Blue
26 BNC AES OUT 4 AES OUT 4 Blue Blue
27 BNC GND AES OUT 5
GND
AES OUT 5 Blue Blue
28 BNC AES IN 8 AES IN 8 White White
29 BNC GND AES IN 8 GND AES IN 8 White White
30 BNC GND AES IN 5 GND AES IN 5 White White
31 162A10019X (DB9.3) BALANCED
SERIAL IN-
(DB9)
SERIAL Red N/A
32 162A10019X (DB9.8) BALANCED
SERIAL IN+
(DB9)
SERIAL Yellow N/A
33 BNC GND AES OUT 8
GND
AES OUT 8 Blue Blue
34 BNC AES OUT 8 AES OUT 8 Blue Blue
35 162A10019X (DB9.1) RS422_FR_GN
D (DB9)
SERIAL Black N/A
35 BNC GND AES IN 2 GND AES IN 2 White White
36 BNC AES IN 1 AES IN 1 White White
37 162A10019X (DB9.9) RS422_FR_GN
D (DB9)
SERIAL Black N/A
37 BNC GND AES IN 1 GND AES IN 1 White White
38 BNC AES OUT 6 AES OUT 6 Blue Blue
39 162A10019X (DB9.7) BALANCED
SERIAL OUT-
(DB9)
SERIAL Blue N/A
40 162A10019X (DB9.2) BALANCED
SERIAL OUT+
(DB9)
SERIAL Green N/A
41 BNC AES OUT 5 AES OUT 5 Blue Blue
42 BNC GND AES IN 6 GND AES IN 6 White White
43 BNC AES IN 6 AES IN 6 White White
44 BNC AES IN 5 AES IN 5 White White
Table 1-4. Pinouts for 44-Pin Connector (Continued)
Pin No. on
DB-44M
Connection Type Description Wire Label
External
Cable Color
BNC
Color
