HMX6803+ and OP+HMX+ Installation and Operation Manual 71
Copyright © 2009, Harris Corporation
Chapter 4: Specifications
RS-232/RS-422
Propagation Delay
Table 4-7. RS-232/RS-422
Item Specification
Standard Electrical specification EIA-232C
Connector
•DB-9
• 232/422 switchable
Table 4-8. HMX6803+/HDX6803+ System Video Propagation Delay
Note: Video delay is bypassed for these measurements
Video Format Video Path Specification
3G HMX6803+ electrical in to fiber out to HDX6803+ fiber
in to electrical out
1.92 µs
HMX6803+ electrical path (SDI in to out) 0.96 µs
HD HMX6803+ electrical in to fiber out to HDX6803+ fiber
in to electrical out
3.6 µs
HMX6803+ electrical path (SDI in to out) 1.75 µs
SD HMX6803+ electrical in to fiber out to HDX6803+ fiber
in to electrical out
11.3 µs
HMX6803+ electrical path (SDI in to out) 5.7 µs
Table 4-9. HMX6803+/HDX6803+ System Video Propagation Delay
Video Format Conditions Delay
When HDX6803+ AES Output Source Selection parameter is set to Audio Proc
SD AES IN to AES OUT; SRCs ON 8.1 ms
AES IN to AES OUT; SRCs OFF 2.3 ms
HD AES IN to AES OUT; SRCs ON 8.7 ms
AES IN to AES OUT; SRCs OFF 3.0 ms
3G AES IN to AES OUT; SRCs ON 8.2 ms
AES IN to AES OUT; SRCs OFF 2.4 ms
When HDX6803+ AES Output Source Selection is set to Demux Ch (Direct, SRC bypassed)
SD / HD / 3G AES IN to AES OUT; SRCs ON 4.7 ms
AES IN to AES OUT; SRCs OFF 1.8 ms
