70 HMX6803+ and OP+HMX+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 4: Specifications
Optical Port (OP+HMX+ Only)
Caution
To prevent overload damage, ensure that you observe the following:
Before connecting any standard-sensitivity (PIN) optical receiver to a fiber
network, ensure the power level is tested to fall within the published
specifications of the receiver. Failure to verify optical power before
connection will void the warranty.
To ensure error-free operation, the input power must be less than -7 Bm.
Table 4-5. Fiber Option Video Output
Item Specification
Number of outputs 1
Connector
• SC/PC per IEC 61754-4-1 (standard)
• ST/PC per IEC 61754-2 (optional)
• FC/PC per IEC 61754-13 (optional)
Table 4-6. Optical Port Performance Specifications - Output (Transmitter)
Item Min Typical Max Conditions
Fixed Wavelength Modules (OP+HMX+13D)
Peak wavelength (FP) 1290 nm 1310 nm 1340 nm
Spectrum width (RMS) (FP) - 2 nm 4 nm
Average output power (FP) -8 dBm -7 dBm -6 dBm
Multiple Wavelength Modules (OP+HMX+CxxD)
Peak wavelength (CWDM) n-3 nm n nm n+3 nm Peak wavelength n = 1270; 1290; 1310;
1330; 1350; 1370; 1430; 1450; 1470;
1490; 1510; 1530; 1550; 1570; 1590;
1610
Average output power
(CWDM)
-1 dBm 0 dBm +2 dBm
All Modules
Extinction ratio 6 dB 8 dB - 2.1 GHz filter (4th order Bessel filter)
Optical rise time - - 135 ps No filter, 20%~80%
Optical fall time - 135 ps 150 ps No filter, 20%~80%
