62 HMX6803+ and OP+HMX+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 3: Operation
Module Status LEDs
HMX6803+ and OP+HMX+ modules do not have any card-edge alarms.
Instead, a module status LED on the corner of the module lights up if an error is
detected. See
Figure 3-10 on page 61 for the location of these LEDs, and
Table 3-12 for a definition of the LED colors.
If the LED is flashing red, please contact your Customer Service
representative.
ELECT IN SEL Green Unused
FIBER IN SEL Green Unused
REF PRES Green Unused
FREEZE Yellow Unused
DARS PRES Green Indicates presence of DARS
AUDIO 1 Green Presence of AES audio on AES input 1
AUDIO 2 Green Presence of AES audio on AES input 2
AUDIO 3 Green Presence of AES audio on AES input 3
AUDIO 4 Green Presence of AES audio on AES input 4
AUDIO 5 Green Presence of AES audio on AES input 5
AUDIO 6 Green Presence of AES audio on AES input 6
AUDIO 7 Green Presence of AES audio on AES input 7
AUDIO 8 Green Presence of AES audio on AES input 8
Table 3-11. Monitoring LEDs (Continued)
LED Color Indicators Meaning
Table 3-12. Module Status LED Descriptions
LED Color Sequence Meaning
Off There is no power to the module; the module
is not operational.
Green There is power to the module; the module is
operating properly.
Red There is an alarm condition.
Flashing red The module has detected a
hardware/firmware fault.
Amber The module is undergoing configuration.
