68 HMX6803+ and OP+HMX+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 4: Specifications
Outputs
SDI Video Outputs
Note
3G HD-SDI video output specifications only apply if you have installed a
HMX68OPT+3G license key
.
Table 4-3. SDI Video Outputs
Item
3G HD-SDI
Specification
1.5G HD-SDI
Specification
SD-SDI Specification
Number 4 processed 4 processed 4 processed
Standard 1080p (SMPTE 424M)
• 1080i (SMPTE 274M)
• 720p (SMPTE 296M)
SMPTE 292M with
SMPTE 299M embedded
audio
SMPTE 259M-C,
270 Mb/s, 525/625
component
Frame rate 1080p: 50, 59.94, 60 Hz
• 1080i: 50, 59.94, 60
• 1080p: 23.98, 24, 25,
29.97, 30 Hz
• 1080psf: 23.98, 24 Hz
• 720p: 50, 59.94, 60 Hz
• 525i 59.94
• 625i 50
Connector BNC (IEC169-8) BNC (IEC 169-8) BNC (IEC 169-8)
Impedance 75Ω 75Ω 75Ω
Return loss
• > 15 dB from 5 MHz to
1485 MHz
• >10 dB from 1485
MHz to 2970 MHz
> 15 dB from 5 MHz to
1485 MHz
> 15 dB up to 270 MHz
Signal level 800 mV ± 10% 800 mV ± 10% 800 mV ± 10%
D.C. offset 0.0 V ± 0.5 V 0.0 V ± 0.5 V 0.0 V ± 0.5 V
Rise and fall time < 135 ps < 270 ps, within 100 ps of
each other
0.4–1.5 ns
Overshoot < 10% of amplitude < 10% of amplitude < 10% of amplitude
Jitter
• >100kHz: < 0.3 UI
(101 ps) pk-to-pk
• >10 Hz: < 2.0 UI (675
ps) pk-to-pk
• >100 kHz: < 0.2 UI
(135 ps) pk-to-pk
• >10 Hz: < 1 UI
(675 ps) pk-to-pk
< 0.2 UI (740 ps) pk-to-pk
Delay Up to 11 frames Up to 11 frames Up to 50 frames
