Chapter 3: Operation
Changing Parameter Settings
You can change parameter settings at the card edge. You can change the
parameter settings, view read-only parameters, view alarms, and adjust alarm
settings using CCS software. See the following topics:
• “Changing Parameter Settings Using Card-Edge Controls” on page 42
• “Changing Parameter Settings Using CCS Software” on page 43
Changing Parameter Settings Using Card-Edge Controls
1. Rotate the hex switch (mode select rotary switch) to 0.
2. Once the hex switch is set to “0,” toggle the navigation switch up or down
to select a bank.
View the two control LEDs next to the navigation toggle switch to see
which bank is currently selected. (See
Table 3-9.)
See Table 3-10 on page 45 to view the various banks, hex switch positions,
and corresponding parameter options and values.
3. Rotate the hex switch to the parameter number (1 to 9) or letter (A to F) of
the option you want to set.
4. Toggle the navigation switch to select and set the value of the chosen
parameter.
5. Do either of the following:
Table 3-9. Selected Bank as Indicated by Control LEDs
Bank Number LED 3 LED 2 LED 1 LED 0
0 Off Off Off Off
1 Off Off Off On
2 Off Off On Off
3 Off Off On On
4 Off On Off Off
5 Off On Off On
6 Off On On Off
7 Off On On On
8 On Off Off Off
9 On Off Off On
A (10) On Off On Off
B (11) On Off On On
C (12) On On Off Off
D (13) On On Off On
E (14) On On On Off
F (15) On On On On
