Chapter 3: Operation
All parameters clip unless otherwise indicated.
Table 3-10. HMX6803+ and OP+HMX+ Parameters
Path Parameter Name
Bank/
Switch
Function Options or User Range
General
Serial Number Displays the module’s
unique identifier
(string)
License Key Activates options String
Installed Options Displays activated options 3G
Factory Recall 0, F Recalls the factory default
settings
• No
•Yes
Laser Wavelength Shows the wavelength of
the laser submodule if the
module is an OP+HMX+;
if the module is a
HMX6803+, this
parameter displays Not
Installed
String
Serial Port
Metadata Interface
Type
12, 8 Selects the metadata
interface type
•RS-232
• RS-422
Input > SDI
SDI Video Standard
Set
0, 1 Selects the SDI video
signal standard
** Standards are available
with the optional 3G HD
license only.
• Auto
• 525i 59.94
•625i 50
• 1080i 50 (295M)
• 1080i 60
• 1080i 59.94
• 1080i 50
• 1080p 30
• 1080p 29.97
• 1080p 25
• 1080p 24
• 1080p 23.98
• 1080psf 24
• 1080psf 23.98
• 720p 60
• 720p 59.94
• 720p 50
• 1080p 60**
• 1080p 59.94**
• 1080p 50**
SDI Electrical IP
Present
Reports the presence of the
SDI input video signal
•No
•Yes
