46 HMX6803+ and OP+HMX+ Installation and Operation Manual
Copyright © 2009, Harris Corporation
Chapter 3: Operation
SDI Electrical IP
Video Std Fb
Reports the detected SDI
video signal standard
• Unknown
• 1080p 25
• 720p 59.94
• 720p 60
• 1080p 23.98
• 1080p 24
• 1080p 29.97
• 1080p 30
• 1080i 50
• 1035i 59.94
• 1035i 60
• 1080i 50 (295M)
• 1080i 59.94
• 1080i 60
• 525i 59.94
• 625i 50
• 720p 50
• 1080psf 23.98
• 1080psf 24
• 720p 29.97
• 720p 30
• 720p 25
• 720p 23.98
• 720p 24
• 1080p 50
• 1080p 59.94
• 1080p 60
Y CRC Error Counter Reports the number of
luminance CRC errors that
have occurred
0 to 16777215
Y CRC Error Counter
Clear
0, 3 Clears the luminance CRC
error counter
• No
•Yes
C CRC Error Counter Reports the number of
chrominance CRC errors
that have occurred
0 to 16777215
C CRC Error Counter
Clear
0, 4 Clears the chrominance
CRC error counter
• No
•Yes
EDH Error Counter Reports the number of
EDH errors that have
occurred
0 to 32767
EDH Error Counter
Clear
0, 5 Clears the EDH error
counter
• No
•Yes
EDH Present Reports the presence of
EDH in the input SDI
signal
•No
•Yes
Input > Genlock/DARS
DARS Present Reports the presence of the
DARS reference signal
•No
•Yes
DARS Locked to
Video
Reports the locked status of
the DARS input signal
•No
•Yes
Table 3-10. HMX6803+ and OP+HMX+ Parameters (Continued)
Path Parameter Name
Bank/
Switch
Function Options or User Range
