HMX6803+ and OP+HMX+ Installation and Operation Manual 47
Copyright © 2009, Harris Corporation
Chapter 3: Operation
Input > Audio > AES
Input AES (1–8)
Present
Reports the presence of the
specified AES input signal
•Yes
•No
Input > Audio > Routing
SRC(1–16) Input
Select
0, 7
•
•
0, E
1, 1
•
•
1, 8
Selects the input audio
source for the specified
Channel’s Sample Rate
Converter
• DMX Grp1 Ch1/2 (Default for SRC1)
• DMX Grp1 Ch3/4 (Default for SRC2)
• DMX Grp2 Ch1/2 (Default for SRC3)
• DMX Grp2 Ch3/4 (Default for SRC4)
• DMX Grp3 Ch1/2 (Default for SRC5)
• DMX Grp3 Ch3/4 (Default for SRC6)
• DMX Grp4 Ch1/2 (Default for SRC7)
• DMX Grp4 Ch3/4 (Default for SRC8)
• AES1a/1b (Default for SRC9)
• AES2a/2b (Default for SRC10)
• AES3a/3b (Default for SRC11)
• AES4a/4b (Default for SRC12)
• AES5a/5b (Default for SRC13)
• AES6a/6b (Default for SRC14)
• AES7a/7b (Default for SRC15)
• AES8a/8b (Default for SRC16)
Input > Audio > V-bit
V-bit Mute Enable 4, C Enables automatic muting
of audio outputs when the
V-bit is set
Note Muting on a detected
V-Bit applies to PCM audio
channels only. Non-PCM
audio channels will not be
muted.
• No
•Yes
Aud Ch(1-32)
(SRC1a-16b) V-bit
Status
Reports the validity bit
status of the specified audio
channel
•Off
•On
Input > Audio > Format
Aud Ch(1-32)
(SRC1a-16b) Format
1, 9
•
•
3, A
Selects the AES format
(Auto/PCM/Non-PCM) of
the selected input audio
channel
• Auto
•PCM
•Non-PCM
Table 3-10. HMX6803+ and OP+HMX+ Parameters (Continued)
Path Parameter Name
Bank/
Switch
Function Options or User Range
